Stack in Data Structures

In the world of data structures, there are very few constructs as simple and powerful as a stack. When you are creating a compiler, you’re dealing with function calls; when designing data-reversal programs, you need to work with stacks; and when solving complex expressions, stacks are a must. In today’s blog, we are going to learn the stack data structure in depth, also known as the Stack, and how it’s so beneficial for us, with a really easy and beginner-level explanation about what a stack is, working of a stack works, and operations on. Stack in Data Structures – A brief introduction and basic operations, applications of stack. Learn about LIFO and how stacks are utilized in algorithms and programming.

What is a Stack?

A stack is a list of elements in which an element may be inserted or deleted only at one end, called the top of the stack.

That means whatever got added last gets removed first.

A good real-life example would be a stack of plates. You keep adding (push) a new plate on the top and taking off (pop) from the top. You never take a plate from the center.

Key Terminology

Some terms to better understand stacks

Push: Adding an element into the stack.

Pop: Popping the top element of the stack.

Peek / Top: To view the top element without popping it.

Overflow: Attempt to OVERFLOW an element where the stack is already full.

Underflow: You attempted to pop a value off the stack that doesn't exist.

How Does a Stack Work?

The stack is nothing but a single opening, and every insertion/delete happens at the same end (top of the stack).

Basic Operations:-

1. Push Operation

• Adds a new element to the stack.

Algorithm:

• Check if the stack is full
• If not full, increment top
• Insert the element at the top position

2. Pop Operation

Pops a value from the top of the stack.

Algorithm:

• Check if the stack is empty
• If not empty, return the top element - or None
• Decrement top

3. Peek Operation

Returns the top element without popping it from the stack.

4. isEmpty / isFull

They are used to verify that the stack is in a certain state before playing with it.

Stack Implementation

Stacks can be implemented using:

1. Array

• Fixed size
• Fast and simple
• But limited because the size cannot change dynamically

2. Linked List

• Dynamic size
• Better memory utilization
• Slightly complex compared to arrays

Example Code (Array Implementation in C):-

#define MAX 5

int stack[MAX];

int top = -1;

void push(int value) {

    if(top == MAX-1)

        printf("Stack Overflow\n");

    else {

        top++;

        stack[top] = value;

    }

}

void pop() {

    if(top == -1)

        printf("Stack Underflow\n");

    else {

        printf("Popped: %d\n", stack[top]);

        top--;

    }

}

Applications of Stack:-

Stacks are a simple concept, but they are super powerful. Here are some popular applications:

1. Function Call Management

When a function is invoked, the program places return addresses, local variables, and arguments onto a stack called the all stack.

2. Undo/Redo Operations

Text editors and drawing programs use stacks to keep track of recent actions.

3. Expression Evaluation

Stacks help convert and evaluate:

• Infix expressions
• Postfix (Reverse Polish Notation)
• Prefix expressions

4. Backtracking Algorithms

Used in solving problems like:

• Maze navigation
• Branch and Bound
• Depth-First Search (DFS)

5. Browser History

Your browser keeps visited pages in a stack. The page supports last-visited-pop on back key press.

Advantages of Stack

• • Easy to implement
• • Quick access to the latest element
• • Useful for recursion and nesting issues
• • Provides controlled access (LIFO)

Disadvantages of Stack

• • Size is limited if done with arrays
• • Not random access to elements as were desired.
• • Underflow and overflow conditions are possible
• • Real-World Examples of Stack
• • Counting Parentheses in Programming ("\)) Here's a question we've been thinking about recently: How many chords can you form from 4 straight lines?
• • Reversing strings
• • Keeping track of past menus on mobile apps
• • Conveyor belt systems that unload items in the opposite order they are loaded

Why Are Stacks Important?

Stacks offer an orderly and straightforward manner of keeping track of information temporarily. They are what make things like function calls, memory management, and evaluating expressions easy. Being LIFO in nature, they are useful for a number of computing applications.

A stack is a very basic data structure that is used heavily in computing technology and various programming languages for computer program execution and temporary data storage. Its strikingly simple LIFO interface lends itself to countless uses — from function calls to expression evaluation to real-world systems like browser navigation and undo.

Stacks are an important concept for anyone in computer science to understand, and it is vitally important that they serve as the underpinning to more complex structures and algorithms. Once you've learned about stacks, the rest will start to make sense: queues, trees, graphs, and memory management.
